WFE-3A2-GDEL-XX

   Cooling Features :

 Type: Direct Cool

 Capacity :

 Gross Volume: 312 Ltr.

 Net Volume: 290 Ltr.

 Net Weight

 72 ± 2 Kg

 Gross Weight

 66.4 ± 2 Kg

 Performance :

 Climate Type (SN, N, ST, T)

 N ~ ST

 Rated Operating Voltage and Frequency

 220-240V~ and 50Hz

 Compressor Input Power (Watt) V 0101- 145.7

 V 0201- 145.7

 Compressor Type V 0101- RSCR

 V 0201- RSCR

 Cooling Efect Freezer Cabinet Less than -18 ̊C

 Refrigerator Cabinet 0 ̊C to +5 ̊C

 General features :

 Temperature Control (Electronic/ Mechanical)

 Mechanical

 Defrosting (Automatic/ Manual)

 Manual

 Reversible Door

 No

 Handle (Recessed/ Grip)

 Recressed/ Grip/ Built-in

 Lock

 Yes

 Refrigerant

 V 0101- R600a

 V 0201- R600a

 Condenser

 V 0101- Copper

 V 0201- MS

 Capillary

 Copper

 Thermostat RoHS Certified

 Polyurethane foam blowing agent

 CycloPentene

 [Eco-friendly (100% CFC &

 HCFC Free) Green Technology]

 Recommended voltage stabilizer capacity Wide Voltage Range (140Vac - 260Vac). Voltage stabilizer is not required.

 In case of voltages beyond this range, 2100VA is recommended

 Refrigerator Compartment :

 Shelf (Material/ No.)

 Wire/2

 Door Basket

 PVC/3

 Interior Lamp

 Yes

 Vegetable Crisper

 Yes (Plastic)

 Vegetable Crisper Cover

 Yes (ABS/ PS)

 Egg Tray or Pocket

 Yes

 Can Storage Dispenser

 No

 Deodorizer

 No

 Freezer Compartment :

 Shelf (Material/ No.)

 Wire/2

 Drawer

 No

 Door Basket

 No

 Interior Lamp

 No

 Net Dimensions :

 Width/mm

 594

 Depth/mm

 708

 Height/mm

 1620

 Packaging Dimensions :

 Width/mm

 625

 Depth/mm

 745

 Height/mm

 1630

 Loading Capacity- 40HQ/ 40Ft/ 20Ft 78/ 57/ 27
