Main Processor: Embedded Processor
Operating System: Embedded LINUX
IP Camera Input: 4+2 each channel up to 6MP
Two-Way Talk: Reuse audio in/out, RCA
Interface: 1 HDMI ,1 VGA
Resolution: 1920×1080, 1280×1024, 1280×720
Multi-Screen Display:
When IP extension mode not enabled: 4CH: 1/4
When IP extension mode enabled: 4CH: 1/4/6
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Compression: H.265+/H.265/H.264+/H.264
Resolution: 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF
Main Stream: 4CH: the 1st channel 5M-N(1~10fps)
Sub stream: CIF/QCIF (1~15fps)
Bit Rate: 32Kbps ~ 6144Kbps Per Channe
Record Mode: Manual, Schedule (General, Continuous), MD (Video detection:
Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval: 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Postrecord: 10 ~ 300 sec
Trigger Event:
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot,
Buzzer and Screen Tips
Video Detection:
Motion Detection, MD Zones: 396 (22 × 18), Video Loss,
Tampering and Diagnosis
Sync Playback: 4CH: 1/4
Search Mode: Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File,
Previous File, Next Camera, Previous Camera, Full Screen,
Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network
Third Party Support: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP
Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung,
Sanyo, Sony, Videotec, Vivotek, and more
Interface: 1 RJ-45 Port (100M)
Network Function : HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter ,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
Maximum User Access: 128 users
Smart Phone: iPhone, iPad, Android
Interoperability : ONVIF 16.12, CGI Conformant
Internal HDD: 1 SATA Port, up to 6TB capacity
USB: 2x USB 2.0
Power Supply: DC12V/1.5A
Power Consumption: <10W
Operational Conditions: -10°C ~ +45°C (+14°F ~ +113°F), 10~ 90% RH
Storage Conditions: -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH
Dimensions: Cooper 1U, 197mm×192mm×41mm (7.8“×7.6”×1.6“)
Net Weight: 0.54kg
Gross Weight: 1kg
