Casing: Metal front cover + plastic main body + metal bracket
Dimensions: 198.4mm×80.2mm×76.2mm (7.81"×3.16"×3.00")
Weight: 0.3Kg
Pan/Tilt/Rotation:
Pan: 0°–360°
Tilt: 0°–180°
Rotation: 0°–360°
Operating Conditions: -40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Storage Conditions: -40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Power Supply: 12V ±30% DC
Power Consumption: Max 5W (12V DC, white light on)
Image Sensor: 1/2.8 inch 2.16 Mega Pixels CMOS
Effective Pixels: 1920 (H)×1080 (V), 2MP
Electronic Shutter Speed:
PAL:1/25s–1/100000s
NTSC:1/30s–1/100000s
Minimum Illumination: 0.005Lux/F1.6, 30IRE, 0Lux white Light on
IR Distance: Distance up to 40m (131.23ft)
IR On/Off Control: Auto; Manual
IR LEDs: 2
Lens Type: Fixed-focal, Fixed iris
Mount Type: M12
Focal Length: 2.8m/3.6mm
Max Aperture: F1.6
Angle of View:
2.8mm: 126.2°×106.0°×56.5° (diagonalxhorizontalxvertical)
3.6mm: 103.6°x86.9°x46.3° (diagonalxhorizontalxvertical)
Close Focus Distance:
2.8mm: 0.6m (1.97ft)
3.6mm: 1.2m (3.94ft)
Resolution:
1080P (1920×1080); 720P (1280×720); 960H (704×
576/704×480)
Frame Rate:
CVI:
PAL: 1080@25fps, 720@25fps, 720@50fps;
NTSC: 1080@30fps, 720@30fps, 720@60fps
AHD:
PAL: 1080@25fps,720@25fps;
NTSC: 1080@30fps,720@30fps
TVI:
PAL: 1080@25fps,720@25fps,720@50fps;
NTSC: 1080@30fps,720@30fps,720@60fps
CVBS:
PAL: 960×576H;
NTSC: 960×480H
Video output:
choices of CVI/TVI/AHD/CVBS by one
BNC port
BLC Mode: BLC/HLC/WDR
Gain Control: Auto; Manual
Noise Reduction: 2D NR
Interface:
Audio Interface: Built-in mic(-A)
Warranty: 1 Year
