Image Sensor: 1/2.7" CMOS
Max. Resolution: 2880 (H) × 1620 (V)
Pixel: 5MP
Scanning System: Progressive
Electronic Shutter Speed:
PAL: 1/25–1/100000 s
NTSC: 1/30–1/100000 s
Min. Illumination: 0.02 Lux/F2.0, 30IRE, 0 Lux IR on
S/N Ratio: More than 65 dB
Illumination Distance: 20 m (66 feet)
Illuminator On/Off Control: Auto;manual
Lens Type: Fixed lens / Fixed iris
Mount Type: M12
Focal Length: 3.6mm (2.8mm Optional)
Max Aperture: F2.0
Angle of View:
2.8 mm: 125° × 106° × 56°
(diagonal × horizontal × vertical)
3.6 mm: 104° × 88° × 46°
(diagonal × horizontal × vertical)
Focus Control: N/A
Close Focus Distance:
2.8 mm: 0.8 m (2.6 ft)
3.6 mm: 1.2 m (3.9 ft)
Pan/Tilt/Rotation:
Pan: 0° – 360°
Tilt: 0° – 78°
Rotation: 0° – 360°
Resolution:
5M (2880 × 1620); 4M (2560 × 1440);
1080P (1920 × 1080);960H (960 × 576/960 × 480)
Frame Rate
CVI:
PAL:5M@25 fps; 4M@25 fps; 1080P@25 fps
NTSC:5M@25 fps; 4M@30 fps; 1080P@30 fps
AHD:
PAL:4M@25 fps;
NTSC:4M@30 fps;
TVI:
PAL:4M@25 fps;
NTSC:4M@30 fps;
CVBS:
960H;
Video Output:
Video output: choices of CVI/TVI/AHD/CVBS by one BNC port
Day/Night: Auto (ICR) / Manual
OSD Menu: Multi-language
BLC Mode: BLC / HLC / DWDR
WDR: DWDR
Gain Control: AGC
Noise Reduction: 2D
White Balance: Auto;manual
Smart IR: Yes
Mirror: Off/On
Privacy Masking: Off / On (8 area, rectangle)
Certifications:
CE (EN55032, EN55024, EN50130-4,EN60950-1,
EN 62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
Audio Interface: N/A
Power Supply: 12V DC ±30%
Power Consumption: Max. 2.7W (12V DC, IR on)
Operating Conditions: –40°C to +55°C (–40°F to +131°F) /Less than 95% RH
*Start up should be done at above –40°C (–40°F)
Storage Conditions: –40°C to +55°C (–40°F to +131°F) /Less than 95% RH
Ingress Protection & Vandal Resistance: NA
Construction: Casing
Plastic:
Dimensions: φ85.4 mm × 68.8 mm (φ3.36 × 2.71")
Net Weight: 0.09 kg (0.20 lb)
Gross Weight : 0.14 kg (0.31 lb)
