Main Processor: Dual-core embedded processo
Operating System: Embedded LINUX
Audio and Video:
IP Camera Input: 8 Channel
Two-Way Talk: 1 Channel Input, 1 Channel Output, RCA
Interface: 1 HDMI, 1 VGA
Resolution:
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720
Decoding Capacity: 1ch@8MP 30fps, 4ch@1080P 30fps
Multi-Screen Display: 4CH: 1/4
8CH: 1/4/8/9
OSD: Camera title, Time, Camera lock, Motion detection, Recording
Compression: H.265/H.264
Resolution: 8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.
Record Rate: 80Mbps
Bit Rate: 16Kbps ~ 20Mbps Per Channel
Record Mode: Manual, Schedule(Regular(Continuous), MD, Stop
Record Interval: 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Trigger Event: Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
Video Detection: Motion Detection, MD Zones: 396 (22 × 18) and Tampering
Alarm Input: N/A
Relay Output: N/A
Sync Playback: 1/4
Search Mode: Time /Date, MD and Exact Search (accurate to second)
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network
Third Party Support: Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more
Interface: 1 RJ-45 port (10/100Mbps)
PoE: N/A
Network Function: HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support Dahua IP camera, DVR, NVS and etc.), Easy4ip
Optical Fiber Interface: N/A
Maximum User Access: 128 users
Smart Phone: iPhone, iPad, Android
Interoperability: ONVIF 2.4, SDK, CGI
Internal HDD: 1 SATA III Port, up to 6TB capacity for each HDD
HDD Mode: Single
eSATAA: N/A
USB: 2 ports (1 Rear USB2.0, 1 Front USB2.0)
RS232: N/A
RS485: N/A
Power Supply: Single, DC12V/2A
Power Consumption: <3W (without HDD)
Operational Conditions: -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions: -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Dimensions: Compact 1U, 260mm×224.9mm×47.6mm (10.2" x 8.9" x 1.9")
Net Weight: 0.8kg (1.76 lb) (without HDD)
Gross Weight: 1.6kg(3.53 lb)(without HDD)
